Specification (產品規格):
The specification of the product are subject to change
without prior notice.
Tubes: Voltage amplifying tube: EF86(6267)x1, ECC81(12AU7, 6189)x1
Pre tube: 6550, KT88, KT90, KT120, KT150, KT170, etc
Circuit configuration: Vacuum tube mono block power amplifier
Output stage: Class-AB push-pull, manual adjustment fixed bias
Heater power:
Voltage amplifying tube: DC power
Output tube: AC power
B-power: MOSFET ripple filter
Max.output (8ohn load, THD10%):
60W (with KT150 or KT170)
50W (with KT88)
Rated input: 1Vrms (With KT150 or KT170)
950mV rms (with KT88)
Frequency response (-3dB): 10-50,000Hz
Residual noise (IHF-A, 8 ohm load): 50uV rms
Input terminal: RCA jack x 1
Output terminal: 8ohm, 4ohm Binding terminal (gold-plated, banana plug compatible)
* Both + and - terminals are insulated from the amplifier circuit and the
chassis ground.
Rated power voltage: 100V AC / 115V AC / 230V AC (selectable upon assembly),
50/60Hz
IEC standard 3P inlet
Rated consumption power:
150W (max. with KT170), 100W (with no signal, with KT170)
130W (max. with KT170), 90W (with no signal, with KT88)
Dimensions: W332 x H214 x D308 mm (incl.projections)
Weight: Approx.10.2kg (assembled, excl.tubes and a power cord)
部件機價 (Kit Set Price) : HKD17,900.00
